SafeLink Bases

The Bolt-on SafeLink Post Baseplate is designed for use with the Safewaze SafeLink HLL System. Mounts securely to steel or concrete structures and used with our 7.5 aluminum post.

Features:

• Use with FS-EX5501-5 aluminum post
• For concrete installations (in 3000 PSI concrete or higher):
  – (4) 1/2 diameter anchor rods with epoxy or
  – (4) 1/2 diameter concrete mechanical anchors
• For steel installation:
  – (4) 1/2 grade 8 bolts with locking hardware

Specifications:

Materials: 3/4″ (19.05 mm) galvanized plate steel Weight: 53 lbs. (24 kg) Height: 12.8″ (325.1 mm Base Dimensions: 12″ (304.8 mm) x 12″ (304.8 mm) Minimum Breaking Strength: 5,000 lbs. (22 kN) ANSI Weight Capacity 130-310 lbs. (59-141 kg) OSHA Standards: 1926.502, 1910.66
