TheBATTIPAV CARGO Plate Handling Trolleyis expertly designed for the transportation and handling of large format tiles and slabs.

Capable of accommodating slabs up to 1600×3200 mm (63″x126″)and a maximum weight of250 kg (551 lbs), this trolley simplifies the movement of heavy materials, even over uneven surfaces.

Features

• Vibration Absorption System:Equipped with special wooden supports that effectively dampen vibrations caused by uneven floors, ensuring the integrity of your slabs during transport.
• Safety Hook:Features a safety hook that securely holds one or more slabs in place, preventing accidental unhooking during movement.
• Swivel Wheels with Brakes:Comes with four pivoting wheels equipped with brakes, allowing for easy maneuverability and stable positioning.
• Fast Assembly and Easy Transport:The aluminum structure offers rigidity with a 30×30 mm (1.18″x1.18″) section for a perfect balance between strength and lightweight design. The trolley can be quickly assembled and disassembled for convenient transportation.
• Compatibility with Battipav Systems:Designed to seamlessly integrate with other Battipav products such as the Agile family, Compact family, Mini Multi Bench, Multi Bench, and Lampo Cut systems.

Technical Specifications

• Maximum Slab Handling Size:1600×3200 mm (63″x126″)
• Maximum Carrying Capacity:250 kg (551 lbs)
• Structure Material:Aluminum with 30×30 mm (1.18″x1.18″) section
• Packaging Dimensions:1320x758x285 mm (52″x29.8″x11.2″)
• Reduced Size for Transport:Easily collapsible for convenient transportation and storage.

Whats Included

• Battipav Cargo Handling System
• Vibration Absorption System
• Safety hook
• Wooden supports
• Swivel wheels with brake
