The 65 Personnel Winch is designed to safely and easily raise and lower workers in confined space applications. Built with high quality materials for smooth and reliable operation even in the toughest environments. This device mounts to both Xtirpa systems and Safewaze tripods.

Features:

• Plastic cable shroud
• Free-wheel mode
• 6:1 gear ratio
• Corrosion resistant cable
• Convenient attached carrying handle
• Matching bracket 019-11010 must be on tripod before mounting (not included)
• Universal mounting bracket fits Xtirpa and Safewaze products
• Unit is service and repair capable

Specifications:

Materials: Powder coated steel device, plated steel components, galvanized steel cable, rubber handles, plastic cover Weight: 35.7 lbs. (16.2 kg) Weight Capacity: 130-310 lbs. (59-141 kg) Material Capacity: Up to 620 lbs. (281 kg) System Capacity: 620 lbs. (281 kg) ANSI Weight Capacity: 130-310 lbs. (59-141 kg) OSHA Weight Capacity: Up to 420 lbs. (191 kg) Max Operation Force: 30 lbs. ANSI Standards: Z359.4-2013, Z117.1-2022 OSHA Standards: 1926.502, 1910.140, 1910.66
