3 Hand Cup With T-Handle for Flat or Curved Surfaces

  • $35.20
  • $44.00
Availability: In Stock

3" Hand Cup With T-Handle for Flat or Curved SurfacesThis compact hand cup has a 15 lbs [7 kg] lifting capacity for the accurate positioning of small flat or curved items. This hand cup can also be used as a mounting cup, with 1/4-20 threaded stud when its


Category:
Share:
payment

3″ Hand Cup With T-Handle for Flat or Curved Surfaces

This compact hand cup has a 15 lbs [7 kg] lifting capacity for the accurate positioning of small flat or curved items. This hand cup can also be used as a mounting cup, with 1/4-20 threaded stud when its handle is removed.

Features:

  • Fast attach and release
  • Doubles as mounting cup – 1/4-20 threaded stud is exposed when handle removed
  • Red-line indicator warns user of any significant vacuum loss
  • Supplied with vacuum pad protector
Model TL3TH SKU 91154 Load Capacity 15 lbs [7 kg] Surface Texture Smooth Material Porosity Nonporous Allowable Surface Curvature Flat to Curved Minimum Radius for Curved Loads 4″ [102 mm] Material and Ambient Temperature-Range 32F [0 C] up to 100 F [38 C] Pad Diameter 3″ [8 cm] Pad Model TL3 Rubber Type Standard Handle Type Industrial-Grade Plastic Plunger Type Industrial-Grade Plastic
