Lasers are typically utilized in the early stages of construction, and measurement needs will vary based on application requirements.

The Makita 12V max CXT Lithium-Ion Self-Leveling Crossline Green Beam Laser (SK105GDZ) gives the user a cordless solution for selectable horizontal/vertical cross reference lines required for level, align, and plumb applications. Depending on ambient light in the working environment, the SK105GDZ has a line visibility range up to 115′ and is detectable up to 262 with a Makita Laser Detector (sold separately).

The SK105GDZ has a bright 525 nm class II green laser with +/-1/8 at 33 for best-in-class accuracy. The laser line fan length spans past the 90-degree position to provide 180 degrees horizontal and 160-degree vertical lines for full reference line coverage. For increased efficiency, self-leveling line stability is achieved in up to 3 seconds for increased productivity.

For longer run time, all 12V max CXT cordless tools are also compatible with the 12V max CXT Lithium-Ion 4.0Ah battery (BL1041B). 12V max CXT lithium-Ion batteries are engineered with a Battery Protection Circuit that protects against overloading, over-discharging and over-heating. Its part of the expanding 12V max CXT series, combining performance with superior ergonomics in a compact size.

For users in the 18V LXT battery platform, the SK105GDZ has a power connector port that allows an 18V LXT battery to be used with the Power Source Adapter (ADP05) and Adapter Cord (adapter and cord sold separately).

Features

• Selectable horizontal/vertical cross reference lines required for level, align and plumb applications
• Makita 12V max CXT 4.0Ah rechargeable battery provides up to 20 hours of continuous run time (battery not included)
• Green line visibility ranges up to 115 depending on ambient light and detectable up to 262′ with Makita Laser Detector LE00855702 (sold separately)
• Bright 525 nm class II green laser for best-in-class visibility with +/-1/8 at 33 for best-in-class accuracy
• Laser line fan angle spans past the 180 horizontal line and 160 vertical line positions for full reference line coverage
• Fast self-leveling line stability is achieved in up to 3 seconds for increased productivity
• Integrated pendulum lock enables slope incline applications and provides added protection of laser diode during transport & storage
• Self-leveling is correctable up to 4 of slope allowing operation on uneven surfaces
• Dust and water resistance with IP 54 rating for increased durability
• Highly protected laser windows are recessed into the housing for increased durability
• Rubberized housing over-mold for increased protection
• Simplified one button user interface for ease of operation
• Low laser brightness mode conserve battery power for extended run-time performance
• Power connector port allows 18V LXT Lithium-Ion Battery to be used as alternate power source with Power Source Adapter (ADP05) and Adapter Cord (adapter and cord sold separately)
• Multi-purpose magnetic bracket with integrated 1/4 & 5/8 threads allow laser attachment to metal surfaces, wood surfaces or Makita Tripods (TK0LM1001F and TK0LM5030F)
• Battery Protection Circuit protects against overloading, over-discharging and over-heating
• Part of the expanding 12V max CXT series, combining performance with superior ergonomics in a compact size
• Not compatible with 12V max pod-style tools, batteries and chargers
• Battery and charger not included
• 3-year limited warranty
• Only use genuine Makita batteries and chargers

Specs

• Battery:12V max CXT Lithium-Ion
• Line accuracy (at 33′):+/- 1/8″
• Line beam direction:2 lines (horizontal, vertical)
• Working range (line):115′
• Working Range with Detector:262′
• Operating time (hours):20
• Laser diode:Class II, 510-530 nm

• Levelling range:4
• Debris resistance:IP54 rating (dust & water resistance)
• Auto shut off:No
• Net Weight (with battery, sold separately):1.9 lbs.
• Laser Beam Color:Green
